Spiral Sand Control Filtration Screen Tube Welding Machine
Description
The spiral welded screen tubes are primarily used sand control filtration in petroleum and chemical industries. Traditionally, there are two types of screen tube for sand control filtration.
Slot Type
Perforated TypeThe machine uses TIG methods for spiral seam welding, offering a clean and stable performance.
Technical Data
| Item | Data |
| Suitable raw material | Carbon steel, stainless steel |
| Raw material thickness | 0.8-2.0mm |
| Material strip width | 100-300mm |
| Filter screen tube diameter | Φ 60-300mm |
| Main driving motor power | 2.2kW |
| Welding method | TIG |
| Cutting method | Plasma non-stop cutting |
| Production speed | 0-15m/min |
| Main machine dimension | 1500 x 1300 x 1400mm |
| Weight | About 1000kg |
